樂袋L1000帶DSP2.1功放模塊30W+10WX2 ，具備14段音頻調(diào)解，設(shè)計(jì)出來的音質(zhì)超棒。

General Description

The L-1000 is a single chip digital audio amplifier Module. Including power stage for stereo amplifier system. The L-1000 is integrated with versatile digital audio signal processing functions， ADC functions， high-performance， high-fidelity Fully digital PWM modulator and two high-power full-bridge MOSFET Power stages. The L-1000 receives digital serial audio Data with sampling frequency from 8KHZ through 96KHZ. It delivers 2 x 30 watts in stereo mode without heat sink. The L-1000 has a mixer and Bi-Quad filters which can Be used to implement the essential audio signal processing Functions like loudness control， compensation of a loud Speaker response and parametric equalization. All the functions of the L-1000 can be controlled by internal Register values from MCU via I2C host interface bus.

Features

1： 2 CH Stereo （30W x 2@24V 6Ohm） 2： 2.1 channel （10W X 2+30W@24V 6Ohm） 3： Wide Operating Supply Voltage Range （7V to 24V） 4： Floating Point Operation 5： 25 Programmable Bi-Quad Filters Speaker Compensation LPF， HPF Parametric Equalizer Loudness Control 6： 100Db Dynamic Range 7： 2 Band Dynamic Range Control 8： 5 Band Graphic Equalizer 9： 3D Surround 10： Protection Circuit OCP （Over Current Protection） OTP （Over Temperature Protection） UVP （Under Voltage Protection） 11： High Efficiency 12： DC cut filter
