PHOTODIODE, 960NM; No. of Pins: 2Pins; Diode Case Style: -; Wavelength of Peak Sensitivity: -; Angle of Half Sensitivity ±: -; Dark Current: 200pA; Operating Temperature Min: -20°C; Operating Temperature Max: 60°C; Product Range: -; Automotive Qualification Standard: -; MSL: -; SVHC: No SVHC (17-Dec-2015); Active Area: 100mm2; External Depth: 2.15mm; External Length / Height: 16.5mm; External Width: 15mm; Height: 16.5mm; Lead Length: 10.5mm; Lead Spacing: 12.5mm; Operating Temperature Range: -20°C to +60°C; Peak Wavelength: 960nm; Reverse Voltage Vr Max: 5V; Rise Time: 3μs; Sensitivity: 0.62A/W; Wavelength Typ: 960nm
Hamamatsu Photonics
PHOTODIODE, 960NM, SMD; No. of Pins: 10Pins; Diode Case Style: -; Wavelength of Peak Sensitivity: -; Angle of Half Sensitivity ±: -; Dark Current: 900pA; Operating Temperature Min: -40°C; Operating Temperature Max: 100°C; Product Range: -; Automotive Qualification Standard: -; MSL: -; SVHC: No SVHC (17-Dec-2015); Active Area: 10mm2; External Depth: 1.26mm; External Length / Height: 16.5mm; External Width: 14.5mm; Operating Temperature Range: -40°C to +100°C; Peak Wavelength: 960nm; Reverse Voltage Vr Max: 30V; Sensitivity: 0.72A/W; Wavelength Typ: 960nm
Hamamatsu Photonics
Silicon Photodiode with Vλ Characteristic, -40 to 100 °C, 3.9 x 6.5 x 1.2 mm
austriamicrosystems (ams)
PHOTODIODE, PREAMP; No. of Pins: 4Pins; Diode Case Style: -; Wavelength of Peak Sensitivity: -; Angle of Half Sensitivity ±: -; Dark Current: -; Operating Temperature Min: -20°C; Operating Temperature Max: 60°C; Product Range: -; Automotive Qualification Standard: -; MSL: -; SVHC: No SVHC (17-Dec-2015); Active Area: 5.8mm2; Bandwidth: 32Hz; External Depth: 4mm; External Length / Height: 10.1mm; External Width: 8.9mm; Lead Length: 5mm; Lead Spacing: 7.4mm; Operating Temperature Range: -20°C to +60°C; Peak Wavelength: 960nm; Supply Current Max: 0.6mA; Wavelength Typ: 960nm
Hamamatsu Photonics
PHOTODIODE, PLANAR CHIP; No. of Pins:1Pins; Diode Case Style:Planar; Wavelength of Peak Sensitivity:930nm; Angle of Half Sensitivity ±:60°; Dark Current:1.7μA; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Product Range:-; Automotive Qualification Standard:-; MSL:-; Active Area:45.9mm2; Breakdown Voltage Vbr:20V; Diode Type:Photodiode; External Depth:10.2mm; External Length / Height:5.1mm; Height:5.1mm; Open Circuit Voltage:0.4V; Operating Temperature Range:-40°C to +125°C; Peak Wavelength:930nm; Reverse Voltage Vr Max:20V; Sensitivity:0.55A/W; Short Circuit Current:2.1mA; Wavelength Typ:930nm
Advanced Photonix
PIN PHOTO DIODE, 20NA, TO-46; No. of Pins: 3Pins; Diode Case Style: TO-46; Wavelength of Peak Sensitivity: -; Angle of Half Sensitivity ±: 18°; Dark Current: 0.02μA; Operating Temperature Min: -55°C; Operating Temperature Max: 125°C; Product Range: SD Series; Automotive Qualification Standard: -; MSL: -; SVHC: No SVHC (07-Jul-2017)
Honeywell
PHOTODIODE, PLANAR; No. of Pins:2Pins; Diode Case Style:Planar; Wavelength of Peak Sensitivity:930nm; Angle of Half Sensitivity ±:60°; Dark Current:3.3μA; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Product Range:-; Automotive Qualification Standard:-; MSL:-; Active Area:109.1mm2; Breakdown Voltage Vbr:20V; Diode Type:Photodiode; External Depth:25.4mm; External Length / Height:5.1mm; Height:5.1mm; Lead Length:130mm; Open Circuit Voltage:0.4V; Operating Temperature Range:-40°C to +105°C; Peak Wavelength:930nm; Reverse Voltage Vr Max:20V; Sensitivity:0.55A/W; Short Circuit Current:6mA; Wavelength Typ:930nm
Advanced Photonix
